3G 4G VR Camera 360 Degree Panoramic IP Camera 960P 1.3MP FIsheye WIreless WiFI Camera IP SD Card Slot Multi Viewing Mode

3G 4G VR Camera 360 Degree Panoramic IP Camera 960P 1.3MP FIsheye WIreless WiFI Camera IP SD Card Slot Multi Viewing Mode

Model: WH-VR-CAM-4G-2.0/3.0MP
Camera Pixels: 2.0MP or 3.0MP
NETWORK: 4G FDD-LTE
Angel:360degree
Description: 3G 4G VR Camera 360 Degree Panoramic IP Camera 960P 1.3MP FIsheye WIreless WiFI Camera IP SD Card Slot Multi Viewing Mode
Inquiry

3G 4G VR Camera 360 Degree Panoramic IP Camera 960P 1.3MP FIsheye WIreless WiFI Camera IP SD Card Slot Multi Viewing Mode

Camera Function

1. H.264 Video Compression

2. 360° view, PTZ

3. Motion Detection function

4. Support SD card storage, Max 64GB

5. Build-in Microphone and Speaker

6. 4G sim card ip camera

4G Function :

1.Industrial grade 4G module

2.Security standard 38 board

3.Support Mobile Network 2G/3G/4G

4.4G wireless transmission rate up to 150m (CAT4)

5.Support up to 10 users access WIFI hotspots.

6.Support WIFI Relay function

7.Send mobile message: *#01# Open 4G connect internet (uim card support SMS)

8.Send mobile message: *#02# Close 4G connect internet (uim card support SMS)

9.Send mobile message: *#03# Open WIFI Function (uim card support SMS)

10.Send mobile message: *#04# Close WIFI Function (uim card support SMS)

11.Send mobile message: *#05# Auto restart 4G modem Function (uim card support SMS)

Model No.		WH-VR-CAM-4G-2.0/3.0MP
Optoelectronic	Lens	f=1.16mm, F=2.0
	Field of View	Horizontal 182°/ Vertical 170°
	Iris	Fixed F2.0
	Sensor	1/3" Progressive Scan CMOS
	Sensibility	0.3Lux@ F2.0(Color)/ 0.03Lux@ F2.0(B/W)
Image	Image Flip	Horizontal/Vertical
	Image Adjustment	Brightness, Saturation, Sharpness, Contrast, Tone
	Max. Resolution	2.0MP (1920 X 1080) OR 3.0MP
	Video Coding	Dual Stream H.264
	Bit Rate	100Kbps~5120Kbps
	Max. Frame Rate	30fps
Audio	Microphone	Internal
	Audio Coding	G.711
	Effective Distance	6 Meters
Pano Function	Panoramic Display	360° panoramic expansion-view, 180° 2 split-view, 90° 4 split-view Longitude and latitude correcting view (wall mounted)
	DPTZ	Digital Pan/Tilt/ Zoom
Intelligent Function	Motion Detection	4 X 3 Regional detecting, Sensibility 1~6 adjustable
Network	Protocol	TCP/IP, HTTP, DHCP, DNS, RTP/RTSP, FTP, PPPOE, SMTP, NTP
	Compatibility	ONVIF2.0
4G modem function	Network type	FDD-LTE TDD-LTE WCDMA/HSDPA/TD-SCDMA EDGE/GPRS/EDGE
	Frequency Scope	LTE B1/B3/B8/B38/B39/B40/B41( B7/B20/B28/B2/B4/)
		TD-SCDMA B34/B39
		WCDMA 2100M/900M GSM 900M/1800M
	Data Rate	LTE FDD/TDD (CAT.4) DL:150Mbps UL:50Mbps
	Data Rate	3G HSDPA+ DL:21Mbps UL:5.76Mbps
	Ethernet Network	A RJ45 Interface 10/100M LAN
	USIM/SIM	Micro SIM card slot
	WIFI Standard	Protocol: 802.11 b/g/n , up to 72Mbps
	WIFI Frequancy	2412MHZ—2472MHZ
	WIFI Security mode	Open, WPA-PSK,WPA2-PSK
Interface	Comm. Interface	1ch 4 pin port 10M/100M Ethernet port
	Power Interface	12v terminal
	Local Storage	Up to 128G SD Card Notice:64G,128G need FAT32 format.
	Day & Night	optional
General	Power Supply	DC12V±10%,1A
	Power Consumption	<6W
	Working condition	-15 °C~+50 °C@Humidity 10%~ 95%
	Storage Condition	-40 °C~+75 °C@Humidity 10%~ 95%
	Housing	PC White
	Protection Grade	IP50
	Product Size	Φ148.5 X 57.5mm
	Weight(kg)	N.W.: 0.5 kg
